Choosing the correct heater size becomes much easier when you can match square footage to wattage. This chart provides a practical reference for common shed sizes, along with guidance on insulation and voltage.
Use this as a starting point when planning your shed heating setup.
If you want a step-by-step explanation of the calculation method, see What Size Electric Heater Do I Need for a Shed?
Basic Wattage Rule
For most backyard sheds:
Insulated shed
10 watts per square foot
Uninsulated shed
12–15 watts per square foot
This formula works well for typical residential sheds with standard ceiling heights.
Shed Heater Size Chart
Below is a general reference chart.
Up to 80 sq ft
Insulated
800 watts
Uninsulated
1,000–1,200 watts
Typical examples: 8×8 shed
Often suitable for a 1,000–1,500W 120V heater.
100 sq ft
Insulated
1,000 watts
Uninsulated
1,200–1,500 watts
Typical example: 10×10 shed
A 1,500W 120V heater usually works well.
See Best Electric Heater for a 10×10 Shed for specific recommendations.
120–150 sq ft
Insulated
1,200–1,500 watts
Uninsulated
1,500–2,200 watts
May require stepping up to a stronger 120V unit or entry-level 240V heater depending on climate.
150–200 sq ft
Insulated
1,500–2,000 watts
Uninsulated
2,000–3,000 watts
Typical example: 12×16 shed
Often best served by a 240V wall or ceiling-mounted heater.
See Best Electric Heater for a 12×16 Shed for detailed guidance.
200–300 sq ft
Insulated
2,000–3,000 watts
Uninsulated
3,000–4,500 watts
Usually requires a 240V hardwired heater.
See Best Electric Heater for a Large Shed (200+ sq ft) for suitable options.
300+ sq ft Workshop
Insulated
3,000+ watts
Uninsulated
4,000–5,000+ watts
These larger spaces almost always require 240V heaters and possibly multiple units.
Ceiling Height Considerations
The chart assumes standard 8-foot ceilings.
If your shed has:
-
9–10 ft ceilings
-
Exposed rafters
-
Open loft areas
You may need additional wattage to compensate for the larger air volume.
Climate Adjustment
Cold climates require more heating capacity.
If winter temperatures regularly drop below freezing:
-
Choose the higher end of the wattage range
-
Consider upgrading to 240V for faster warm-up
Mild climates allow you to stay closer to the lower end of the range.
120V vs 240V Reference
120V heaters
Typically max out at 1,500 watts
Best for sheds under 150 sq ft
240V heaters
Offer 2,000–5,000+ watts
Better for medium to large sheds
If you’re unsure about electrical setup, see Do You Need a Dedicated Circuit for a Shed Heater?
You can also compare:
Final Thoughts
This size chart provides a reliable starting point for most residential sheds.
To choose the right heater:
-
Measure square footage
-
Identify insulation level
-
Adjust for climate
-
Match wattage to voltage
For a complete overview of heater types and installation styles, return to Best Electric Heater for a Shed (Complete Buyer Guide).
